Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

बड़ी छवि : Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

उत्पाद विवरण:

उत्पत्ति के प्लेस:	ज़िन्ज़िआंग
ब्रांड नाम:	ZR BLOWER
प्रमाणन:	CE, ISO 9001
मॉडल संख्या:	4-72 श्रृंखला

भुगतान & नौवहन नियमों:

न्यूनतम आदेश मात्रा:	1
मूल्य:	50-50000
पैकेजिंग विवरण:	लकड़ी की पैकिंग
प्रसव के समय:	5-45 दिन
भुगतान शर्तें:	एल/सी, डी/ए, डी/पी, टी/टी
आपूर्ति की क्षमता:	10000

संपर्क करें

Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

वर्णन

प्रकार:	इंडस्ट्रियल हाई प्रेशर ब्लोअर	सामग्री:	स्टील, 316L, कार्बन स्टील / स्टेनलेस स्टील, Q235
वोल्टेज:	220V/380V/440V/480V/660V	ब्लेड सामग्री:	स्टेनलेस स्टील, कच्चा लोहा, स्टील प्लेट, Q345 (16Mn) मैंगनीज स्टील
शक्ति:	5 - 350 किलोवाट	हवा की मात्रा:	800 - 90000m3 / एच
गारंटी:	1 वर्ष	रंग:	ग्राहक की आवश्यकता
अनुप्रयोग:	शीतलन प्रणाली	नाम:	औद्योगिक अक्षीय फ्लो फैन
प्रमाणन:	CE, ISO 9001	बिक्री के बाद सेवा प्रदान की:	विदेशों में सेवा मशीनरी के लिए उपलब्ध इंजीनियर, ऑनलाइन समर्थन
प्रोडक्ट का नाम:	बॉयलर निकास पंखा औद्योगिक निकास केन्द्रापसारक निकास ब्लोअर, चीन आपूर्तिकर्ता बॉयलर एयर ब्लोअर पिछड़े	आकार:	ग्राहक का अनुरोध
विशेषता:	उच्च दक्षता	आवेदन:	परिवहन सामग्री और गैस, सीमेंट संयंत्र, निकास वेंटिलेशन, बॉयलर निकास, उच्च दबाव मजबूर वेंटिलेशन
प्रमुखता देना:	backward centrifugal fan high pressure , backward curved centrifugal blower forced ventilation , 9-26 type centrifugal fan material conveying

Backward Centrifugal Fan For High Pressure Forced Ventilation And Non-Viscous Material Conveying 9-26 Type Backward Curved Centrifugal Blower

Inline duct fan Small Centrifugal Blower Fan 9-26 Type Rolling Bearings exhaust centrifugal blower cooling blower fan. 9-26 high pressure centrifugal fan is generally used for forging furnace and high pressure forced ventilation, and can be widely used for conveying materials and conveying air and non-corrosive, non-spontaneous combustion, non-viscous substances of gas.

The temperature of the medium is generally not more than 50°C (the highest is not more than 80°C), and the dust and hard particles contained in the medium are not more than 150mg/m³.

Installation Steps

Before installation, the components of 9-26 type high-pressure centrifugal fan should be comprehensively inspected, whether the rotation direction of the impeller and the casing is consistent, whether the connection of each part is firm, and whether there is any friction after the impeller rotation.
During the installation, pay attention to check that no tools and debris should be left in the shell. The connection of the inlet and outlet air pipes should be naturally consistent.
For the coupling or fan with transmission, check whether the coupling or belt wheel and belt are installed reliably.
9-26 type high pressure centrifugal fan installed, test run, can be in the fan starts must in no load adjustment door shut down the wind coming into the wind to adjust slightly open under the situation of induced draft fan for boiler.
When the 9-26 type high-pressure centrifugal fan reaches the normal speed after starting, it should be checked whether the bearing temperature is normal (generally not higher than 80°C).

Maintenance Guidelines

Only the high-pressure centrifugal fan can operate under the condition that the equipment is completely normal.
If the fan equipment is started after maintenance, it is necessary to pay attention to whether each part of the fan is normal.
Regularly remove dust, dirt and other impurities inside the fan, and prevent rust.
In order to ensure personal safety, the maintenance of the fan must be carried out during parking.

Operation Notes

In the process of starting, stopping or running the high-pressure centrifugal fan, if abnormal phenomena are found, they should be checked immediately.
In addition to the lubricant should be replaced after each maintenance, the lubricant should be replaced according to the actual situation under normal circumstances.

Key Features

Impeller diameter: 90~3500 mm

Speed of mainshaft: 560~2900 rpm

Pressure range: 3000~25425 Pa

Flow range: 1297~43305 m³/h

Air Temperature: 20~1000°C

Material: Cast Iron, Carbon Steel, Stainless Steel

Efficiency: 80%-90%

Applications

Cement

Industrial boiler

Power generation

Chemical processing

Combustion-support

Cooling systems

Corrosive gas

Dryer

Dust collection

Forced draft

Fume exhaust

General ventilation

Incineration

Induced draft
